12. Artifacts

Jobs can output an archive of files and directories. This output is known as a job artifact. You can download job artifacts by using the GitLab UI.

Example of an artifact definition:

pdf:
  script: xelatex mycv.tex
  artifacts:
    paths:
      - mycv.pdf
    expire_in: 1 week

The paths keyword determines which files to add to the job artifacts. All paths to files and directories are relative to the repository where the job was created.

The expire_in keyword determines how long GitLab keeps the job artifacts. You can also use the UI to keep job artifacts from expiring. If expire_in is not defined, the instance-wide setting is used.

Task 12.1: Artifacts Lab

  • Add an artifacts section to the build_image job
  • Add an artifact with the name container-scanning-report_<identifier>.txt
  • Define the artifact paths pointing to file that the Trivy command writes.
  • Set a retention time of 30 days for the artifacts

Task 12.2: Artifacts Lab solution

Updated .gitlab-ci.yml file for this lab:

show solution
stages:
  - info
  - build
  - test
  - package
  - deploy

include:
  - project: '${CI_PROJECT_NAMESPACE}/${CI_PROJECT_NAME}'
    file:
      - 'templates/k8s.yml'
      - 'templates/Secret-Detection.yml'
  - template: Security/SAST.gitlab-ci.yml
  - template: Security/License-Scanning.gitlab-ci.yml

variables:
  GIT_STRATEGY: 'clone'
  COMPILE: 'false'
  IMAGE_HOST: 'quay.io'
  IMAGE_REPOSITORY: 'puzzle'
  IMAGE_NAME: 'example-spring-boot'

default:
  timeout: 5 minutes

info:
  stage: info
  retry: 2
  script:
    - echo "This is your first stage (ツ)"
    - echo "Username is ${USERNAME} with ${PASSWORD}"

build_application:
  stage: build
  tags:
    - build
    - mobiliar
  image: registry.access.redhat.com/ubi9/openjdk-17:latest
  script:
    - ./gradlew assemble

test_application:
  stage: test
  image: registry.access.redhat.com/ubi9/openjdk-17:latest
  script:
    - ./gradlew check
  artifacts:
    when: always
    reports:
      junit: build/test-results/test/**/TEST-*.xml

build_image:
  image: diemobiliar.azurecr.io/dlp-cicd-dockercli-image:254
  tags:
    - build
    - mobiliar
  services:
    - docker:dind
  stage: package
  before_script:
    - docker info
    - export TRIVY_VERSION=$(wget -qO - "https://api.github.com/repos/aquasecurity/trivy/releases/latest" | grep '"tag_name":' | sed -E 's/.*"v([^"]+)".*/\1/')
    - echo $TRIVY_VERSION
    - wget --no-verbose https://github.com/aquasecurity/trivy/releases/download/v${TRIVY_VERSION}/trivy_${TRIVY_VERSION}_Linux-64bit.tar.gz -O - | tar  -zxvf -
  script:
    - docker build --no-cache -t $IMAGE_NAME .
    - mkdir -p reports
    - ./trivy i --exit-code 0 --severity CRITICAL -o reports/container-scanning-report_$CI_COMMIT_SHORT_SHA.txt $IMAGE_NAME
    - IMAGE_PATH=$IMAGE_HOST/$IMAGE_REPOSITORY/$IMAGE_NAME:${CI_COMMIT_SHA:0:8}
    - echo "docker image path is - $IMAGE_PATH"
    - docker tag $IMAGE_NAME $IMAGE_PATH
    # - docker login -u ${DOCKER_USERNAME} -p ${DOCKER_PASSWORD} ${IMAGE_HOST}
    # - docker push $IMAGE_PATH
  artifacts:
    name: "container-scanning-report_$CI_COMMIT_SHORT_SHA.txt"
    paths:
      - reports/container-scanning-report_$CI_COMMIT_SHORT_SHA.txt
    expire_in: 30 day

deploy_to_prod:
  stage: deploy
  when: manual
  only:
   - release
  script:
    - echo "Deployment triggered"

deploy_to_k8s:
  stage: deploy
  extends: .kubectl
  tags:
    - build
    - mobiliar
  script:
    - echo "deploy your stuff here with kubectl commands"
    - kubectl version --client --short

Download Job Artifacts

The defined artifact can be found on the build_image Job detail page of this Pipeline. Find the Job artifacts section on the right side beside the Job log.

Click on Download to get the Trivy report file and open it to see the report.

Task 12.3: Pipeline Artifacts Lab

Go to your pipeline Build –> Pipelines and click on the download menu ⍗ to see the downloadable artifacts.

Then download them and open the JUnit test report.

Download artifacts
